Two Phase Production Separators


Two Phase Production Separators

We design and supply for Offshore and Onshore oil & gas production process. Our Separators equipped with State of-art separation technology with All the internals, Inlet, discharge devices for the most efficient separation of Sand, Gas, water from oil.

OUR PRODUCT SPECIFICATIONS ARE
  • Max Crude handling Capacities: 140,000 Bbl/day Oil + Water
  • 200 MMSCFD separated up to 0.1% carryover
  • Gas Pressure: 50 PSIG, Temperature: 125 Deg C
  • Max Dimensions: 4500 mm DIA / 18500 MM T/T Skid Mounted
  • Product Specifications: 100 % Removal of 10 micron particle

A vessel that separates the well fluids into gas and total liquid. A two-phase separator can be horizontal, vertical or spherical. The liquid (oil, emulsion) leaves the vessel at the bottom through a level-control or dump valve.The gas leaves the vessel at the top, passing through a mist extractor to remove the small liquid droplets in the gas.
